Token optimisation — Headroom & RTK

Two external tools can cut the tokens a session burns, and ainb wires both in per session — opt-in, never global:

Headroom — a local LLM-API compression proxy. A session’s Claude/Codex CLI is pointed at it via ANTHROPIC_BASE_URL / OPENAI_BASE_URL, so requests are compressed on the way out.
RTK (Rust Token Killer) — a Claude Code PreToolUse hook that compresses tool output (Bash / test / diff) before it reaches the model.

Both are toggled when you create a session, both degrade gracefully when the binary isn’t installed, and the savings show up live in the TUI.

Per session

Toggled on the Configure screen — one session can route through Headroom while another goes direct to Anthropic.

Reflects reality

The statusline HR badge and the Savings tab read actual routing (the inherited base-URL env), not the stored toggle.

Fault-tolerant

Availability-gated, degrades to direct if the proxy can’t start, and a watchdog respawns it if it dies mid-session.

Turn it on for a session

Headroom and RTK are rows on the Configure screen when you start a new session (provider must be Claude or Codex for Headroom; RTK is Claude-only). Use ← / → to flip each toggle.

ainb new-session Configure screen showing the per-session Headroom toggle — Headroom on / [off] with arrow keys to change, a greyed note that it is a proxy that trims token usage with a link to the headroom GitHub

The Headroom row on Configure. The toggle is per session — flip it on here and only this session routes through the proxy. If the headroom binary isn’t on PATH, the row shows unavailable with an install hint instead of a toggle, so you can never arm a proxy that can’t exist.

How routing works

The toggle is intent. When a session launches with Headroom on, ainb first ensures the shared proxy is healthy, then injects the base-URL export into that session’s CLI:

export ANTHROPIC_BASE_URL='http://127.0.0.1:8787' && exec claude    # Claude
export OPENAI_BASE_URL='http://127.0.0.1:8787/v1' && exec codex     # Codex

If the proxy can’t come up, the session degrades to direct — it launches without the base-URL so it talks to the provider straight, never to a dead port. A session with the toggle off always goes direct. The default port is 8787 (override with AINB_HEADROOM_PORT).

Statusline `HR` badge

A routed session shows an HR pill on the Claude Code statusline — green when the proxy is live, grey when the session is routed but the proxy is down. It reads the base-URL env the statusline process actually inherited, so it tells you whether requests are really being compressed, not just whether you flipped the toggle.

See what you saved — the Savings tab

Open the usage screen with i, then press ] to cycle the outer tabs to Savings:

ainb usage Savings tab — the Token Savings card with a live green Headroom row showing real saved tokens, RTK not installed, a modelled caveman estimate at times 0.74, and a NET measured total of Headroom plus RTK

The Savings card pulls savings.total_tokens straight from the live proxy’s /stats: ● Headroom 907K live. RTK shows installed/not-installed and its own saved total. The caveman row is a modelled estimate (×0.74, labelled est) and is never counted as real. NET (measured) = Headroom + RTK only.

CLI surfaces

Every surface has a headless equivalent — ainb headroom status, ainb rtk status, ainb usage savings, and ainb doctor (which lists both as token-opt deps):

ainb doctor listing rtk and headroom as token-opt dependencies, ainb rtk status reporting honestly when rtk is not installed, and ainb usage savings printing the Headroom live tokens, RTK, caveman estimate and NET

See the CLI reference for the full subcommand list.

Fault tolerance

Token optimisation is best-effort: it must never break a session. Every failure mode degrades cleanly.

fault-injection harness — the watchdog starts the proxy within seconds and respawns it with a new pid after a kill, and both the Headroom and RTK rows gate to unavailable when the binary is moved aside; 4 passed 0 failed

Failure	Behaviour
Binary not installed	Toggle shows `unavailable` + an install hint; can’t be armed
Proxy can’t start at launch	Session runs direct (no dead-port injection), logs a warning
Proxy dies mid-session	An in-loop watchdog (~10 s) respawns it; recovery is “next request succeeds”
Last routed session closes	The shared proxy is idle-reaped
Proxy misbehaves mid-session	Press `H` on the session to downgrade to direct (`claude --continue`)

Install

Headroom (Python tool):

uv tool install 'headroom-ai[proxy]'    # or: pipx install 'headroom-ai[proxy]'

RTK (Claude only):

brew install rtk
# or: curl -fsSL https://raw.githubusercontent.com/rtk-ai/rtk/master/install.sh | sh

Re-open the Configure screen — the rows are now real toggles instead of unavailable.
