abtop plugin

abtop surfaces real-time AI coding-agent monitoring inside ainb by wrapping the external abtop binary. It is a subprocess-wrapping plugin in the same pattern as witr: pressing t in ainb hands the full terminal to abtop’s own native TUI, returning to ainb on quit — every abtop key works natively, no translation layer.

Press t from any ainb screen (or select the abtop sidebar tile) to open abtop’s live agent-monitor full-screen. First launch shows the rate-limit consent dialog.

What is abtop?

abtop is a htop-style TUI that watches every AI coding agent (Claude Code, Codex, and others) running on the machine: token usage, rate-limit headroom, cost burn, active sessions, and hook-triggered status updates. It is maintained by graykode and is never bundled into ainb — it is detected at runtime.

How it works

The screen is a host-embedded foreign TTY, exactly like witr. abtop’s value is its own live interactive monitor — there is no machine-readable wire format for the live view. Pressing t (or the sidebar tile 📡) queues AsyncAction::AttachAbtop: ainb runs tmux new-session -A -d -s ainb-abtop "abtop --exit-on-jump", suspends its own TUI, and attaches full-screen to abtop’s native monitor. When the user quits abtop, ainb resumes. The plugin’s render method is never invoked for the screen; this wiring lives entirely in ainb-core.

The CLI path is different: ainb abtop [args] execs abtop --once [args] directly, inheriting the parent terminal’s stdio so abtop’s --once snapshot prints cleanly (it only emits a one-shot snapshot against a real TTY, then exits). Args are forwarded verbatim, so any flag abtop itself accepts works: ainb abtop --theme <name>, etc. (The in-tree ainb-plugin-abtop crate also exposes the same surface over plugin/cli_dispatch for the plugin harness, but the live ainb abtop command is wired directly in ainb-core.)

First-launch consent — abtop ships an optional --setup hook that installs a Claude Code StatusLine hook to feed live rate-limit data. On the very first open of the screen, ainb displays a one-time dialog so the user can opt in (or skip) before anything writes to ~/.claude. ainb never writes ~/.claude without an explicit “Enable” choice.

Capabilities

Capability	Declared value	Why it is needed
spawn_subprocess	["abtop"]	Exec abtop --once (CLI path) and abtop --exit-on-jump (the full-screen handoff). Detection is a PATH lookup (which abtop) — present/absent only, no version probe and no exec. The list form is per-binary audit metadata.

All other capabilities (read_sessions, read_claude_logs, read_codex_logs, write_plugin_data, event_bus, network) are left at their deny default.

Using it

Screen (t key)

Press t from any ainb screen, or select the abtop / “top-for-agents” entry in the sidebar (shortcut t, icon 📡).

ainb suspends and full-screen-attaches to abtop’s native TUI running inside a managed tmux session (ainb-abtop). Every abtop key works natively — ainb does not intercept or translate them. Press q (or abtop’s quit binding) to close abtop and return to ainb.

If abtop is not on PATH, the screen renders an install empty-state with the canonical install command for your platform rather than silently failing.

First-launch consent dialog

On the very first time the screen is opened, ainb shows a one-time consent dialog:

Choice	What happens
Enable	Runs abtop --setup to install the Claude Code StatusLine hook, then opens the monitor. ainb writes to ~/.claude only on this path.
Just open abtop	Opens abtop without running setup. The hook is not installed. Dialog shown again next time.
Don’t ask again	Opens abtop without running setup, and suppresses future prompts. The choice is persisted as a marker file under ~/.agents-in-a-box/.

The dialog also stops appearing once the rate-limit hook has been installed (ainb detects ~/.claude/abtop-rate-limits.json). You can re-run the hook setup at any time by invoking abtop --setup directly.

Live monitor

Once open, you are in abtop’s own interactive TUI. All of abtop’s modal keys pass through natively. Common navigation (taken directly from abtop):

Key	Action
↑ / ↓	Select an agent row
Enter	Jump to the selected agent’s tmux pane (then exits abtop back to ainb, via --exit-on-jump)
x	Kill the selected session
/	Filter sessions
v	View menu (tree, timeline, panel toggles)
c	Config overlay
?	Help — abtop’s full keybinding list
q	Quit abtop, return to ainb

These are abtop’s own keys (verified against the v0.4.7 footer bar), not ainb’s — press ? inside abtop, or see abtop’s docs, for the complete reference.

CLI (ainb abtop)

ainb abtop shells abtop --once and exits. Any extra args are appended after --once and forwarded verbatim to the binary:

ainb abtop                     # one-shot status snapshot (runs `abtop --once`)
ainb abtop --theme <name>      # forwarded verbatim → `abtop --once --theme <name>`

abtop emits human-readable text only — it has no JSON mode, so there is no --format json variant here. Because the command always prepends --once, it is for snapshots; the full-screen monitor and the one-time abtop --setup hook are reached from the TUI (press t), not from ainb abtop.

If abtop is not found on PATH, the CLI prints an install hint and exits with code 1.

Installing abtop

abtop is an external binary maintained by graykode. ainb detects it at runtime — install whichever way fits your environment:

macOS (Homebrew — recommended)

brew install graykode/tap/abtop

Linux (installer script)

curl -sSL https://github.com/graykode/abtop/releases/latest/download/abtop-installer.sh | sh

Any platform (Cargo)

cargo install abtop

After installing, confirm it is on PATH:

abtop --version

ainb picks up the binary on the next launch; no ainb restart is required within an existing session.

Source

crates/ainb-plugin-abtop — detects the external abtop binary, owns the ainb abtop CLI via abtop --once exec, handles first-launch consent state, and renders the missing/install empty state; the foreign-TTY screen handoff (t → abtop --exit-on-jump) is wired in ainb-core.
