Shared MCP pool

Every Claude Code session normally spawns its own node/bun process for each configured MCP server. Run a swarm of sessions and that multiplies into dozens of processes hogging CPU and RAM (anthropics/claude-code#45880 reports kernel panics from 510 node processes). The shared MCP pool fixes this: a standalone ainb mcp daemon spawns each MCP server once behind a unix socket, and every session attaches through a tiny ainb mcp proxy stdio shim. N sessions, one backend process.

Two sessions attach to a real context7 server and both receive its tools (resolve-library-id, query-docs). ainb mcp status reports clients: 2 against one child_pid — a single shared process group. Without the pool, those two sessions would spawn two separate context7 servers.

510 processes

node procs that kernel-panicked a Mac — claude-code#45880.

80% fewer

processes measured by the community shared-proxy workaround (7 sessions × 5 servers).

11/11 green

live e2e assertions pass — scripts/validate-mcp-pool.sh.

The problem: MCP process explosion

MCP’s stdio transport is one-client-only by design — the client launches the server as a subprocess and owns its stdin/stdout pipe. So every session that wants a server spawns its own copy. Multiply by a swarm of worktree sessions and the math gets ugly fast: Anthropic issue claude-code#45880 reports 15 sessions × 34 servers demanding up to 510 node processes — enough to trigger hardware-watchdog kernel panics. The community workaround (a shared HTTP proxy) measured an 80% process / 77% memory reduction. ainb bakes that win in natively, no extra runtime.

Quick start

1. The pool is on by default — there’s nothing to enable for a basic setup.

2. Point at any project that has MCP servers in its .mcp.json (or in ainb config), then start a session as usual:

   ainb run --repo . --worktree

   ainb ensures the daemon is running and rewrites the worktree’s .mcp.json so each pooled server points at the shim.

3. Confirm sessions are sharing one backend:

   ainb mcp status   # look for "clients": N against a single "child_pid"

Walkthrough — from scratch

The full journey in one recording: a project whose only MCP config is a plain .mcp.json, made poolable with ainb mcp import, two sessions attaching to a real context7 server, and the proof that both share one backend process.

Every command in the recording is one you’d run yourself. Reproduce it with scripts/mcp-pool-journey.sh (real context7, isolated $HOME, no Claude auth needed).

Wire it up — per agent

The shim is just a stdio command, so any agent CLI can funnel into the same backend processes. Claude is automatic; Codex and Copilot need one wiring command.

Claude

Zero-config — the pool is wired automatically when you ainb run.

1. Have your MCP servers in the project’s .mcp.json (or in ainb config).

2. Start a session:

   ainb run --repo . --worktree

   Stdio servers in the worktree’s .mcp.json are auto-imported into the pool and the file is rewritten to point at the shim. Nothing else to do.

3. Verify:

   ainb mcp status

Codex

Codex reads a global MCP config, so wire it once.

1. Install the pool shim into Codex’s config (a .bak backup is written first):

   ainb mcp install --codex

   This adds shim entries to ~/.codex/config.toml pointing at the pool sockets.

2. Make sure the daemon is up — any ainb Claude session starts it, or run it yourself:

   ainb mcp daemon &

3. Start Codex. Its MCP sessions now share the same backend processes as your Claude sessions.

Copilot

Same one-time wiring for GitHub Copilot CLI.

1. Install the pool shim into Copilot’s config (a .bak backup is written first):

   ainb mcp install --copilot

   This writes shim entries into ~/.copilot/mcp-config.json.

2. Ensure the daemon is running:

   ainb mcp daemon &

3. Start Copilot — its MCP servers now attach to the shared pool.

Wire both at once with ainb mcp install --codex --copilot. A Codex session, a Copilot session, and three Claude sessions then all funnel into the same context7 process.

Configure the pool

Pool settings and per-server opt-out live in config.toml (user-level ~/.agents-in-a-box/config/config.toml, or per-repo .ainb/config.toml), or in the TUI under Configuration → MCP Pool. You usually don’t have to hand-write any of this — see the .mcp.json and import tabs.

config.toml

# ~/.agents-in-a-box/config/config.toml   (user-level)
# …or  ./.ainb/config.toml                (per-repo override)

[mcp_pool]
enabled = true          # default true
idle_grace_secs = 300   # reap a pooled server N seconds after its last session detaches

[mcp_servers.context7]
name = "context7"
description = "docs server"
enabled_by_default = true
shared = true           # set false for stateful servers (browser/db bridges) → per-session spawn
installation = { type = "PreInstalled" }
definition = { type = "Command", command = "npx", args = ["-y", "@upstash/context7-mcp"] }

.mcp.json (zero-config)

You don’t have to declare servers in ainb config at all. A project whose only MCP config is a plain .mcp.json:

{
  "mcpServers": {
    "context7": { "command": "npx", "args": ["-y", "@upstash/context7-mcp"] }
  }
}

ainb run auto-imports the stdio entry, registers it with the daemon, and rewrites .mcp.json to point at the shim. Remote (http/sse) entries are left alone — there’s no local process to pool.

import

Persist .mcp.json + Claude user-scope servers into ainb config so they’re managed explicitly:

ainb mcp import          # → ./.ainb/config.toml  (project)
ainb mcp import --user   # → ~/.agents-in-a-box/config/config.toml  (user-level)

Existing config entries are never overwritten; comments and formatting are preserved.

status

ainb mcp status

{
  "servers": [
    {
      "name": "context7",
      "clients": 2,
      "child_pid": 40859,
      "state": "running"
    }
  ]
}

clients: 2 against a single child_pid is the proof two sessions share one process.

Monitor the pool

Open the MCP entry in the home sidebar (or press p for pool) for a live overlay of what’s served right now — and which sessions share each backend process.

Two sessions sharing one context7 process — the overlay names them (api-session, web-session) against a single pid. The session label is the ainb session name, passed through the shim’s --session flag.

What the table shows per server: state (running / grace / idle / failed), shared (✓ ×N when more than one session is attached), the session names, the backend pid, spawn count, and uptime.

Actions:

• i — import: pulls stdio servers from your Claude user scope (~/.claude.json) — plus the launch directory’s .mcp.json if there is one — into the global user config (~/.agents-in-a-box/config/config.toml), then registers any new ones with the live daemon so they appear in the table immediately, no session restart. The overlay is a global pool view (it isn’t bound to any worktree), so import targets the user config — the one config read from anywhere; per-worktree .mcp.json servers are already auto-imported at session create. Import is additive: existing entries are never overwritten, and servers whose command doesn’t resolve on the host are skipped. The result (▸ imported …) shows in a line above the help bar.
• s — stop server (confirmed): reaps the selected server’s process; attached sessions reconnect and the next attach respawns it.
• X — stop pool (confirmed): shuts the whole daemon down; every session falls back to its own MCP processes.
• r refreshes on demand; esc / q closes.

Press i in the overlay to bring servers in from .mcp.json without dropping to a shell — it writes the config and registers them live.

It costs nothing when closed

The overlay is lazy by design. It fetches the daemon’s status once on open, then (while open) auto-refreshes every monitor_refresh_secs (default 2; set 0 for on-open + manual only). The control-socket read runs off-thread, so the TUI never blocks; and when the overlay is closed, nothing polls — there is no background monitor. Configure under [mcp_pool]:

[mcp_pool]
monitor_refresh_secs = 2   # 0 = refresh on open + `r` only

How it works

 session A ──stdio── ainb mcp proxy ──┐
 session B ──stdio── ainb mcp proxy ──┼─ unix socket ─ ainb mcp daemon ─ 1× context7 (npx)
 session C ──stdio── ainb mcp proxy ──┘   (id-rewrite mux, init cache, refcount)

A tool call fans in: many stdio shims, one socket, one child.

1. A session attaches. At session create, ainb run ensures the daemon is up, then rewrites the worktree’s .mcp.json so each pooled server’s entry becomes the shim (ainb mcp proxy <socket>). When the agent launches that “server”, it’s really launching the shim — a line-framed stdio↔socket bridge with exponential-backoff reconnect, so a daemon blip recovers in seconds.

2. The daemon lazy-spawns the real server. The first client to connect triggers the one-and-only spawn of the actual MCP command (e.g. npx -y @upstash/context7-mcp), in its own process group so npx/uvx grandchildren die with it. Restarts are rate-limited.

3. The mux multiplexes every client onto that one child. Each client’s JSON-RPC request id is rewritten to a mux-global counter so two sessions both opening at id:1 never collide; the mapping is stored so responses can be addressed back.

4. Responses route to the right session. The mux restores the original id and forwards the reply to only the owning session; progress notifications route by progressToken. When the last client detaches, a grace timer (idle_grace_secs) reaps the child.

If anything fails — daemon down, server not on PATH — the session silently falls back to spawning its own MCP, so a session never fails to start because of the pool. Host/tmux sessions only; Docker sessions keep their per-container MCP init.

The hard parts the mux had to solve

A naive byte-pipe (the agent-deck approach this started from) leaks state across sessions. The ainb mux fixes the two worst cases so a shared server behaves correctly per-client.

Initialize cache

MCP servers expect exactly one initialize per process lifetime, but every session sends its own. The mux forwards the first one, caches the backend’s InitializeResult, and answers every later session’s initialize from that cache — the child sees one handshake, every client gets a valid reply with its own id. Errors aren’t cached, so a failed handshake retries cleanly.

progressToken routing

Progress notifications carry a token, not a request id. The mux records which session owns each token at call time and delivers progress to that session only — so session A’s “50% done” doesn’t broadcast to B and C.

v1 limitations

Server-initiated requests (sampling, elicitation, roots) still broadcast — most pooled tool-servers don’t use them. Stateful servers (browser/db bridges) should opt out of sharing with shared = false and keep spawning per-session, since env/credentials bake in at spawn and are shared by every attached session.

Gotchas worth knowing

• Host/tmux sessions only. Docker sessions keep their per-container MCP init — the pool doesn’t touch that path.
• The daemon reads config at its cwd, so sessions in other projects push their server definitions over the control socket (register) rather than relying on what the daemon saw at startup.
• Shared identity. Env/credentials bake in at spawn and are shared by every attached session — fine for tool servers, a reason to set shared = false for anything per-user-authenticated.
• Failure never blocks a session. Daemon down, server not on PATH, socket gone — the session silently falls back to spawning its own MCP, exactly like today.

Commands

Command	What it does
ainb mcp daemon	Run the pool daemon in the foreground (auto-spawned detached by ainb run)
ainb mcp status	Per-server JSON: client count, shared child pid, state
ainb mcp stop	Stop the daemon and its pooled children
ainb mcp import [--user]	Import stdio servers from .mcp.json / Claude user scope into config
ainb mcp install --codex --copilot	Point other agent CLIs at the pool shim
ainb mcp proxy <socket>	The stdio↔socket shim (used inside generated .mcp.json; you won’t call it directly)

FAQ

Does it work for any MCP, or just npm/npx?

Any stdio server — npx, uvx, bun, a compiled binary, docker run -i. The mux speaks newline-delimited JSON-RPC over the child’s stdio, which is identical regardless of runtime. Remote http/sse servers aren’t pooled (there’s no local process to share).

What stops two sessions’ requests from colliding?

The mux rewrites every request id to a global counter and remembers which session owned the original id, so responses and progress route back to exactly one session. Claude Code always starts ids at 1 — that’s the collision this prevents.

How was “one process” actually proven?

Two ways. The committed GIF drives real context7 with two shim attaches and reads child_pid + the process group. And scripts/validate-mcp-pool.sh 3 spins up three real ainb Claude sessions and asserts one backend, three shims, a working tool call from every session, kill-one-survives resilience, and post-grace reaping — 11/11 green.

What happens when a pooled server crashes mid-call?

The daemon reaps the zombie and drops the clients; their shims reconnect with backoff while the health loop respawns the child (rate-limited). In-flight requests are lost and the agent retries — the same contract a per-session server gives you.

Verify it yourself

The compact GIF at the top is recorded from a reproducible demo that uses real context7:

cargo build --release
AINB_BIN=ainb-tui/target/release/ainb scripts/mcp-pool-demo.sh

A heavier end-to-end check spins up three real ainb Claude sessions and asserts one backend process, three shim attachments, a working tool call from every session, kill-one-survives resilience, and post-grace reaping:

scripts/validate-mcp-pool.sh 3
